TOA CS-760B Two-Way Weatherproof Horn Speaker

Price: 1 ৳

Regular Price: 1 ৳

Status: In Stock

Product Code: CS-760B

Brand: TOA

Key Features :

The CS-760B is a compact 2-way weatherproof speaker system designed for high efficiency, high power input handling capacity, and is a high intelligible speaker suited for public address announcement and BGM application in a fully outdoor environment. Being IP-66 certified, external speaker component finished to ensure the unit’s weatherproof ability and special paint coat prevents color degradation, ensuring it’s long-lasting exterior condition. This model is designed with a rotary switch that facilitates hassle-free impedance change.

- +

Description

Professional-Grade Power for Extreme Outdoor Environments

The TOA CS-760B Two-Way Horn Speaker is built for professional, long-range public address where maximum output, clarity, and durability are non-negotiable. With a powerful 60-watt input and an exceptional maximum sound pressure level of 117 dB, it delivers intelligible audio that cuts through extreme ambient noise over vast distances. Its rugged IP66 rating certifies it as completely dust-tight and protected against powerful water jets, making it reliable for permanent outdoor installation in Bangladesh’s challenging climate, from coastal areas to industrial zones.

Full-Range, Two-Way Clarity with Wide Dispersion

Unlike basic single-driver horns, the TOA CS-760B employs a sophisticated two-way speaker system with a dedicated 16 cm woofer and a 2.5 cm dome tweeter, crossed over at 2.5 kHz. This design delivers a full frequency response from 100 Hz to 20 kHz, ensuring both the power of low-frequency signals and the crisp clarity of voice announcements. The rectangular horn provides a controlled 90° (H) x 80° (V) directivity angle, offering wider, more uniform sound coverage than traditional narrow-beam horns.

Specification

Model	TOA CS-760B
Rated Input	60 W (70V / 100V Line)
Max. Sound Pressure Level	117 dB (60W, 1m)
Sensitivity	100 dB (1W, 1m)
Frequency Response	100 Hz – 20,000 Hz
Speaker System	Two-Way: 16 cm Woofer + 2.5 cm Dome Tweeter
Crossover Frequency	2.5 kHz
Directivity	90° (Horizontal) x 80° (Vertical)
Protection Rating	IP66 (Totally Dust-tight & Protected against powerful water jets)
Enclosure Material	ABS, Steel, Stainless Steel Bracket
Dimensions & Weight	388 (W) x 310 (H) x 367 (D) mm / 7.4 kg
Mounting Options	Bracket included; Compatible with poles, walls, stands (see Options)

Primary Applications

Industrial Complexes & Manufacturing Plants: For site-wide announcements and safety alerts.
Transportation Hubs: Railway yards, bus depots, ports, and ferry terminals.
Sports Stadiums & Large Outdoor Venues: For crowd control and announcements.
Agricultural & Aquacultural Facilities: Fish farms, poultry farms, and large estates.
Any Outdoor Area requiring loud, clear, and weatherproof sound projection.
